Specifications
Contact Rating: 5 Amp with resistive load at 125 VAC or 28 VDC
Electrical Life: 50,000 make or break cycles at full load
Contact Resistance: 10mW max. initial @ 2-4 VDC
100mA for both coin silver and gold plated contacts.
Insulation Resistance: 1,000 MW min.
Dielectric Strength: 1,000 V RMS @ sea level
Operating Temperature: -30°C to 85°C

Materials
Case: melamine or diallyl phthalate (DAP)
Toggle Handle: Brass, chrome plated
Bushing: Brass, nickel plated
Housing: Stainless steel
End Contact: Coin silver, silver plated
End Terminal: Brass, silver plated
Center Contact & Terminal: Brass, silver plated

8011

1+ $1.12ea.

10+ $0.93ea.

100+ $0.75ea.
