   ADLINK PCIS_LVIEW PNP is a Plug and Play LabVIEW™ driver for it's flagship NuDAQ data acuisition cards and is fully compatible with National Instruments™ easy-to-use LabVIEW™ hardware programming interface CLICK HERE for a downloadable version for Win-95/98/NT/2000/XP
 |
| ||||||||||||||||||||
| 80MB/Sec 32Ch Digital Input / 32Ch Output Card(PCI-7300A) PCI-7300A Our fastest digital I/O card. Up to 80 megabytes per second transfer rate. Programmable to 16-bit or 32-bit. 64K (16DW) FIFO. Scatter-gather bus mastering DMA.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 12MB/Sec 32Ch Digital Input / 32Ch Output Card(PCI-7200) PCI-7200 32-bit digital I/O card. Up to 12 megabytes per second transfer rate using handshaking. 64byte (32W) FIFO.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 96-Bit Digital I/O Card(PCI-7296) PCI-7296 96-bit digital I/O card. Emulates four industry standard 8255 PPIs at mode 0. Directly interfaces with OPTO-22 compatible I/O modules.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 48-Bit Digital I/O Card(PCI-7248) PCI-7248 48-bit digital I/O card. Emulates two industry standard 8255 PPIs at mode 0. Directly interfaces with OPTO-22 compatible I/O modules.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 32Ch Isolated DI & 32Ch Isolated DO Card(PCI-7432) PCI-7432 The highest density isolated DIO PCI card available. I/O ports are accessed by 32-bit I/O instructions, thus increasing data throughput. 32ch 5000Vrms photo-isolated digital input channels. 32 isolated digital output channels are driven by Darlington transistors capable of 500mA current sink suitable for driving relays.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 64Ch Isolated Digital Input Card(PCI-7433) PCI-7433 The highest density isolated Digital Input PCI card available. I/O ports are accessed by 32-bit I/O instructions, thus increasing data throughput. 64ch 5000Vrms photo-isolated digital input channels.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 64Ch Isolated Digital Output Card(PCI-7434) PCI-7434 The highest density isolated Digital Output PCI card available. I/O ports are accessed by 32-bit I/O instructions, thus increasing data throughput. 64 isolated digital output channels are driven by Darlington transistors capable of 500mA current sink suitable for driving relays.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 32 Channel Isolated Digital I/O Card(PCI-7230) PCI-7230 16 isolated digital inputs and 16 isolated digital outputs. 5000Vrms voltage isolation.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 16-CH Latching Relay Outputs & 16-CH Isolated DI Card (PCI-7256)
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 32Ch Isolated Digital Output Card(PCI-7234) PCI-7234 32 isolated digital output channels. 5000Vrms voltage protection. 200mA sink current.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 8 Relay, 8 Isolated Digital Input(PCI-7250) PCI-7250 8 channel relay outputs and 8 channel isolated digital inputs card. Relays and driving circuits onboard. LED indicator for each relay. Expandable to 32 relays and 32 Isolated inputs in 8ch increments using the PCI-7251 add-on modules.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 12Ch Timer/Counter & DIO Card(PCI-8554) PCI-8554 Four 8254 (82C54) Timer/Counter chips on-board. 10 independent 16-bit down counters, 2 cascaded counters based on 8MHz system clock. Programmable clock sources for each counter. 8 TTL DI and 8 TTL DO.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 3Ch AB Phase Encoder & PWM Output Card(PCI-8133) PCI-8133 4-Axis motion control card. Can generate high-frequency pulses to drive stepper motors and/or pulse train input servomotors. This device is capable of continuous motion control, in-positioning and origin return in various ways including constant speed and linear acceleration/deceleration.
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 32-CH Isolated Digital Input with COS Detection (PCI-7233) PCI-7233 32 isolated digital input channels. 2500Vrms voltage protection. Change-of-state (COS) detection on all 32 channels .
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| High Speed Isolated 32-CH DI Card with COS (PCI-7233H )
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| High Driving Capability 48-CH DIO Card (PCI-7348)
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| High Driving Capability 96-CH DIO Card (PCI-7396)
| |||||||||||||||||||
| ||||||||||||||||||||
| ||||||||||||||||||||
| 32-CH PhotoMos Relay Outputs & 2-CH Isolated DI Card (PCI-7258)
| |||||||||||||||||||
|
